In-line PCB Depaneling System CNC PCB Router Separator For PCB
Assembly
Specification :
1. X,Ｙcutting speed :1 ~100mm/s
2. Re-orientation accuracy :± 0.01mm
3. X,Y,Z Control model :Industry IPC and PC
4. X,Y,Z Way of actuation :AC servomotors
5. Operation and data storage :PC system
6. Cutting accurancy :± 0.1mm
7. Ratation of principal axis :MAX60000rpm
8. Voltage:220V 1φ 50 / 60HZ
9. Air press supply :more than 4.5kg/cm²
10. Power consumption:3KVA
11. Dust collection method :Lower dust collection
12. Precipitron :Voltage:220V (380V) 3φ
13. Size of upper precipitron:500×500×1000mm
14. Size of lower precipitron :665×635×1610mm
Description of various models
| | Model | Discription | Working area | Machine size D×W×H | Machine+PrecipitronWeight |
| One fixture type | SS | small fixture,updraft | 400×400mm | 1200×1150×1450mm | 650 kg |
| SL | Large dixture,updraft | 500×450mm | 1200×1150×1450mm | 650 kg |
| SD | Small fixture ,downdraft | 400×450mm | 1200×1150×1450mm | 790 kg |
| SW | large fixture,downdraft | 500×450mm | 1200×1150×1450mm | 790 kg |
| Two fixture type | DS | Standard Type | 285×340mm | 1470×1150×1450mm | 800 kg |
| DL | Lengthening type | 285×450mm | 1470×1150×1450mm | 800 kg |
| DW | Widening type | 350×450mm | 1470×1300×1450mm | 840 kg |
| DX | Extra wide type | 500×450mm | 1470×1600×1450mm | 1050 kg |
| DM | Widening and lengthening type | 350×550mm | 1470×1700×1700mm | 980 kg |
| AT | IN-LINE type | 300×350mm | 1470×2000×1620mm | 1300 kg |
Why choose us
1. Engineers available to service machinery oversea.
Engineers are available to be sent to freign countries to do
machinery training and offer technical support.
2. One year warranty for the machines except accessories.
Robust frame construction and Japanese steel blades obtained good
appraise and recognized by and oversea clients. We offer parts for
replacement under warranty free of charge, clients only need to
bear freight charge.
3..Effective customer service.
All of us together are stronger and wiser than any one of us
individually. To succeed, we must assume responsibility, cooperate
with fellow associates and withdepartments, effectively comminicate
with one another, foster enthusiam and participate in
decision-making. To be seay reachable by customers and provide
prompt replies to solve their problems and create value for
customers
4. Mature technique & forerunner to process makes high quality
machinery.
As largest manufactory in South China, we have 12 years experience
on PCB separator machines and soldering machines. pcb router
machine
Our R&D team continuously upgrade the existing machines to meet
the market development trend
About us
| Dongguan ChuangWei Electronic Equipment Manufactory was founded in
2004,is located in the world manufacturing city
Dongguan,Guangdong,China. The company is committed to
development,manufacture,sales and service for professional pcb
separator/pcb depanelizer electronic equipment machinery. The
company has advanced production and processing equipment and an
experienced development and manufacture team, half of them have
over 10 years experience in electronic equipment industry. |
| Begin with 2004 the company leader invested to develop and
manufacture the PCB separator and PCB depaneling machine. From then
on we pay more attention to product quality, safe to use and
product innovation, so far we have produced many high quality,
stable performance, high cost-effective products. Improve
production yields, increase productivity, and thus enhance the
market competitiveness of our customers. |
| Until now we have design different separating PCB types of PCB
separator and PCB depaneling machine with manual, motor-driven,
pneumatic-driven, mold punching, milling cutter router. Due to the
good quality and reasonable price our customers are all over the
world. Up to now ChuangWei have became one of the biggest PCB
separator production base in China |
Company always insists to the "customer needs is our goal, creating
most value for customers", strives to provide customers with
first-class products, first-class service. So since date
established we very attached importance to product
quality,continuous improvement for manufacturing process,try hard
to save money for customers.
|
| Our great mission is to be the most professional and excellent
supplier in the pcb separator/pcb depanelizer electronic equipment
industry. |
