AC90V - 260v 300w Automated Dispensing Machines Teach Pendant
Features :
1 , Could be a particular dispensing operations, mechanized
production
2 , Simple and convenient to operate , high-speed precision
3 , Program files can be uploaded/downloaded through U disk ,easy
to manage
4 , Has control buttons on the needle , no external teaching is
more convenient than similar products debugging
5 , Used LCD 5-inch color screen display
6 , Does not cause noise pollution to production sites
7 , Enabling 3D dispensing systems , regardless of any comple shape
and dispensing path can be accurately completed
8 , Can be equipped with single-tube or pipe dispensing , improve
efficiency in the realization of different glue or dispensing path
9 , Used for in all kinds of demand dispensing industry , such
as:general common UV plastic , silicon , EPOXY , red gum , paste ,
AB glue ,
COB vinyl , conductive plastic , aluminum heat glue , instant
glue,paste and other points glue ,
can be used on the D-series devices .
Sepcification :
| Travel RangeX/Y/Z | 300/300/100 (mm) |
| Table Max Load | 10KG |
| Z Axis | 4.5KG |
| Moving SpeedXY/Z | 0.1-800 / 400 (mm / sec) |
| Analytical Ability | 0.01mm / Axis |
| Repeatability | ±0.01mm / 200mm |
| Program Recording Capacity | 1000 |
| Display | 5 Inch LCD |
| Motor | Japan micro-level precision stepper motor |
| Moving Mode | Point to point , Continuous line |
| Transmission | Japanese belt , Precision linear guide |
| Motion Makeup Function | 3 Axis |
| Edit Mode | Teach box or computer file input |
| I / O Signal | 6In puts 6 Out puts |
| Power | AC 220V / 350W |
| Operating Temperature | 5 - 40℃ |
| Operating Humidity | 20 - 90 % ( no condensation ) |
| Size ( mm ) | 522 x 560 x 565 |
| Weight ( kg ) | 62.5 |
Applications :
1 , LED package
2 , Mobile phone plate coating or dispensing button
3 , Speaker Dispensing
4 , Dispensing sealing the battery case
5 , The semiconductor package
6 , Power component package
7 , chip binding
8 , Fixed and protected PCB electronic components
9 , LCD glass board package
Details :
Package information : plywood case
